Enter/Exit Programming Mode
Product Reference Guide
149
Code 11 Set Length 1
This feature specifies one of the bar code lengths for Code 11 Length Con-
trol
. Length 1 is the minimum label length if in Variable Length Mode, or the
first fixed length if in
Fixed Length Mode. Length includes the bar code’s
check and data characters. The length can be
se
t from 2 to 50 characters.
Table 16 provides some examples for setting Length 1. See page 267 for
detailed instructions on setting this feature.
Table 16. Code 11 Length 1 Setting Examples
STEP ACTION EXAMPLES
1
Desired Setting (pad with
leading zeroes)
02 Characters 07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODE 11 LENGTH 1 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘2 ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
$CC1L1
Select Code 11 Set Length 1 Setting
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
~
CANCEL
DEFAULT
04 = Length 1 is 4 Characters
