CONFIGURE ACTIONS FOR FUNCTION KEYS
Each of the function keys can be programmed to perform a user-assigned
function. This is done by associating a function key with either a predefined
command or your own custom string. See the "
Defin
e Strings" on page
25
1
command to define customized strings.
Each function key has an associated la
bel
which shows in the display when
active. The default labels are shown in the table below. To program the
function key labels, see "
Set S
tring ID" on page 252
.
T
he following table shows the list of predefined commands and available
stri
ngs.
Table 26. Keyboard Programming
CMD_ID Name Function
Default
Label
0 Not configured
No configured action.
If a key must be kept enabled but in normal mode isn’t
requir
ed, this function can be selected to keep it inactive.
Whenever an unconfigured function key is pressed, an error
message appears on display and an error beep is emitted.
<None>
1 Enter CMD Same as ENTER_KEY. Ent
2 String 1 Display and transmit string 1. S1T
3 String 2 Display and transmit string 2. S2T
4 String 3 Display and transmit string 3. S3T
5 String 4 Display and transmit string 4. S4T
6 String 5 Display and transmit string 5. S5T
7 Backlight CMD Toggle backlight on/off. Blt
8 Clear CMD Clears the screen CLR
9 Reserved for future use
A Reserved for future use
B Show Date/Time Display the internal date, time. Tim
C Reserved for future use

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
