Introduction
6 PowerScan™ PD9530/PBT9500/PM9500
charge / charge cycles before needing replacement. This number is higher if
partial discharging / recharging is adhered to rather than full / deep dis-
charging,
The typical manufacturer advertised useful life
of LI batteries is one to three
years, depending on usage and number of charges, etc., after which they
should be removed from service, especially in mission critical applications.
Do not continue to use a battery that is showing excessive loss of capacity, it
should be properly recycled / disposed of and replaced. For most applica-
tions, batteries should be replaced after one year of service to maintain cus-
tomer satisfaction and mini
mi
ze safety concerns.
Collect and recycle waste batteries separately from the device in compliance
with Euro
pean Directive 2006/66/EC, 2011/65/EU, 2002/96/EC and 2012/
19/EU and subsequent modifications, US and China regulatory and others
laws and regulations about the environment.
Programming the Reader
Configuration Methods
Programming Bar Codes
The reader is factory-configured with a standard set of default features.
After scanning the interface bar code, you can select other options and cus-
tomize your reader through use of the instructions and programming bar
code
labels available in the corresponding features section for your inter-
face. Customizable settings for many features are found in
"Configuration
Parameters"
st
ar
ting on page 21.
Some programming labels, like
"Restore Custom Defaults" on pa
ge 18,
require only the scan of the single label to enact the change. Most, however,
require the reader to be placed in Programming Mode prio
r to scanning
them. Scan an ENTER/EXIT bar code once to enter Programming Mode. Once
the reader is in Programming Mode, scan a number of parameter settings
before scanning the ENTER/EXIT bar code a second time, which will then
accept your changes, exit Programming Mode and return the reader to nor-
mal operation.
There are some exceptions to the typical programming sequence
described above. Please read the description and setting instructions
carefully when configuring each programmable feature.
Datalogic Aladdin™
Datalogic Aladdin™ is a multi-platform utility program providing a quick and
user-friendly configuration method via the RS-232/USB-COM interface.
Aladdin allows you to program the reader by selecting configuration com-
mands through a user-friendly graphical interface running on a PC. These
co
mm
ands are sent to the reader over the selected communication interface,
or they can be printed as bar codes to be scanned. Aladdin also facilitates
image capturing.
In addition, Aladdin makes it easy to upgrade the handheld’s firmware, to
attain the be
nefits of new reader features. Reference the Datalogic Aladdin™
Online Help for more details.
Aladdin is available for download free of charg
e on the Datalogic website.

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
