Datalogic PowerScan PBT9500 User Manual

Enter/Exit Programming Mode
212 PowerScan™ PD9530/PBT9500/PM9500
Docking Beep
Enables/disables a beep indication when the handheld is placed in the Base
Station.
$CBTCB00(CR)
Docking Beep = Disable
$CBTCB01(CR)
Docking Beep = Enable
DEFAULT
Leash Alarm
This setting specifies the number of seconds to sound the Leash Mode
beeps (three per second) when the handheld goes out of range. This is
especially useful in instances where the reader might inadvertently have
been placed in a bag or cart.
For this mode to be effective, the reader m
ust be linked to the Base Station.
If the reader is asleep or disconnected from the Base Station, there is no way
for it to know where it is relative to the Base Station because communication
is not active between the devices.
DEFAULT
$CBTLB00(CR)
Leash Alarm = Disabled
$CBTLB01(CR)
Leash Alarm = 1 Second
$CBTLB02(CR)
Leash Alarm = 2 Seconds

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
