Enter/Exit Programming Mode
Product Reference Guide
161
Code 93 Set Length 1
Specifies one of the bar code lengths for Code 93 Length Control. Length 1
is the minimum label length if in
Variable Length Mode, or the first fixed
length if in
Fixed Length Mode. Length includes the bar code’s data charac-
ters only. The length can be set from 01 to 50 characters.
Table 20 provides some examples for setting Length 1. See page 267 for
detailed instructions on setting this feature.
Table 20. Code 93 Length 1 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
01 Characters 07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODE 93 LENGTH 1 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
$CC9L1
Select Code 93 Set Length 1 Setting
Make a mistake? Scan the CANCEL bar code to abort
and not save the entry string. You can then start
again at the beginning.
~
CANCEL
DEFAULT
01 = Length 1 is 1 Character
