Datalogic PowerScan PBT9500 User Manual

Technical Specifications
304 PowerScan™ PD9530/PBT9500/PM9500
Error Codes
Upon startup, if the reader sounds a long tone, this means the reader has
not passed its automatic Selftest and has entered FRU (Field Replaceable
Unit) isolation mode. If the reader is reset, the sequence will be repeated.
Press and release the trigger to hear the FRU indication code.
The following table describes the LED flashes/beep codes as
sociated with an
error found.
NUMBER OF
LED FLASHES/
BEEPS
Error CORRECTIVE ACTION
1 Configuration
Contact Helpdesk for
assistance
2 Interface PCB
6 Digital PCB
11 Imager
Base Station Indications (Cordless Models ONLY)
Base Station Button Indicators
BUTTON PUSH
EVENT
CORDLESS
RED
INDICATOR(**)
GREEN
INDICATOR(**)
Push at power-up
force device connection
(Ala
ddin)
Off
Slow blink
Fast blink
< 5 sec Paging Off Fast blink
5 to 10 sec Unlink (Only Bluetooth) Off Slow blink
Programming Mode Indications (continued)
INDICATION DESCRIPTION LED BEEPER
Label Program-
ming Mode Accep-
tance of
Programming
Con
figuration option(s)
have be
en successfully
programmed via labels
and the reader has exited
Programming Mode.
N/A
Reader sounds one
high frequency
beep
and 4 low fre-
quency beeps fol-
lowed by reset
beeps.
Label Program-
ming Mode Cancel
Item Entry
Cancel label has been
sc
anned.
N/A
Reader sounds two
ti
me
s at low fre-
quency and current
volu
me.

Datalogic PowerScan PBT9500 Specifications

General

Type	Handheld bar code reader
Wavelength	680 nm
Sensor type	Laser
Scanner type	1D/2D
Tilt reading angle	0 - 360 °
Pitch reading angle	0 - 40 °
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	-
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code
Battery life	10 h
Charging time	4 h
Battery capacity	2150 mAh
Power source type	Battery
Number of reads per charge	30000
Number of batteries supported	1
Wireless range	100 m
Operating frequency	2400 - 2480 MHz
Standard interfaces	USB, RS-232
Connectivity technology	Wired & Wireless
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Buzzer	Yes
Certification	IEC 62471 Class 1 LED
Product color	Black, Yellow
Protection features	Shock resistant, Water resistant
International Protection (IP) code	IP65
Cables included	RS-232

Weight and Dimensions

Depth	74 mm
Width	110 mm
Height	212 mm
Weight	380 g
