Appendix A
Technical Specifications
The tables that follow contain Physical and Performance Characteristics,
User Environment and Regulatory information.
Table 52 provides Standard
Cable Pinouts.
Table 51. Technical Specifications
Item Description
Physical Characteristics
Dimensions
Height: 212 mm
Length: 110 mm
Width: 74 mm
Weight (without cable) 330 gr (without cable)
Electrical Characteristics
PD9530 models
Voltage & Current
PD9530/
PD9530-HP
PD9530-HPE PD9530-DPM
Input Voltage 5 VDC +/- 5% 10 to 30 VDC 5 VDC +/- 5%
Input Current
Operating (typical): 335mA 135mA @ 10V 350mA
Operating (max): 475mA 300mA @ 10V 480mA
Idle/Standby (typical) 180mA 60mA @ 10V 120mA
PBT9500 and PM9500 models
Battery Type Li-Ion battery pack
Charge time for full
charge fro
m full dis-
charge
4 hours with external power supply adapter
a
a. Charge Times are much lower when battery is within daily typical operating condition.
Typical 10 hours with Host power (in this case no supply
adapter is needed)
a
Operating autonomy
(continuous reading)
30,000 reads (typical)
Cradle consumption and
DC in
put supply range
Volt 10-30 VDC; Power <8W
b
b. Typical input current measured under factory default configuration.
;
Max 500mA when in host/bus powered mode
b
.
