Performance Characteristics
Light Source LED
Roll (Tilt) Tolerance ± 180°
Pitch Tolerance ± 40°
Skew (Yaw) Tolerance ± 40°
Print Contrast
Minimum
15% minimum reflectance
Standard Optics Model High Performance (HP)
Resolution
Max resolution 1D 4 mils
Max resolution 2D 7.5 mils
1D 2.5 mil
2D 4 mil
Depth of Field (Typical)
a
Symbology Standard Optics Model High Performance (HP)
Code 39
4 mils: 6-17 cm
20 mils: 4-55 cm
40 mils: 4-85 cm
2.5 mils: 2-6 cm
20 mils: 3-70 cm
40 mils: 3-110 cm
EAN 13 13 mils: 4-48 cm 13 13 mils: 3-60 cm
PDF-417 10 mils: 2-25 cm 10 mils: 2-30 cm
DataMatrix
7.5 mils: 7-14 cm
10 mils: 4-18 cm
4mil: 2-6 cm
10mil: 2-20 cm
Minimum Element
Wi
dt
h
Standard Range:
1D Minimum Resolution = 4 mil
PDF-417 Minimum Resolution
= 5 mil
Data Matrix Minimum Resolu-
tion
= 7 mil
High Density:
1D Minimum Resolution
= 2.5 mil
PDF-417 Minimum Resolution
= 4 mil
Data Matrix Minimum Resolu-
tion = 5 mil
a
13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade A, 300 lux ambient light, 20°C,
label inclination 10°
Technical Specifications
298
PowerScan™ PD9530/PBT9500/PM9500
