Need help?Do you have a question about the Datalogic PowerScan PBT9500 and is the answer not in the manual?
General| Type | Handheld bar code reader |
|---|---|
| Wavelength | 680 nm |
| Sensor type | Laser |
| Scanner type | 1D/2D |
| Tilt reading angle | 0 - 360 ° |
| Pitch reading angle | 0 - 40 ° |
| Light levels (direct sunlight) | 0 - 100000 lx |
| Linear (1D) barcodes supported | - |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, MaxiCode, Micro QR Code, QR Code |
| Battery life | 10 h |
| Charging time | 4 h |
| Battery capacity | 2150 mAh |
| Power source type | Battery |
| Number of reads per charge | 30000 |
| Number of batteries supported | 1 |
| Wireless range | 100 m |
| Operating frequency | 2400 - 2480 MHz |
| Standard interfaces | USB, RS-232 |
| Connectivity technology | Wired & Wireless |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -20 - 50 °C |
| Operating relative humidity (H-H) | 0 - 95 % |
| Buzzer | Yes |
| Certification | IEC 62471 Class 1 LED |
| Product color | Black, Yellow |
| Protection features | Shock resistant, Water resistant |
| International Protection (IP) code | IP65 |
| Cables included | RS-232 |
Weight and Dimensions| Depth | 74 mm |
|---|---|
| Width | 110 mm |
| Height | 212 mm |
| Weight | 380 g |
