Datalogic PowerScan PD9630-HP

DECODING CAPABILITIES
PRODUCT REFERENCE GUIDE 309
DECODING CAPABILITIES
DOF - DEPTH OF FIELD (TYPICAL)
A
a. All labels grade A, typical environmental light, 20°C, label inclination 10°
Symbology DOF range
Code 128
PM96XX:
5 mils: 6.4-30.9 cm (2.5-12.2 in)
20 mils: 4-103.7 cm (1.6-40.8 in)
40 mils: 5.5-175 cm (2.2-68.9 in)
PM96XX-HP:
2.5 mils: 6.3-11.5 cm (2.5-4.5 in)
5 mils: 3.8-41 cm (1.5-16.1 in)
20 mils: 4-157 cm (1.6-61.8 in)
40 mils: 5.5-242.9 cm (2.1-95.6 in)
EAN13
PM96XX:
13 mils: 4-67.5 cm (1.5-26.5 in)
PM96XX-HP:
13 mil: 4-120.2 cm (1.5-40.2 in)
PDF417
PM96XX-HP:
10 mils:0.5-46.1 cm (0.2-18.1 in)
Datamatrix
PM96XX:
10 mils: 6.4-10 cm (2.5-3.9 in)
PM96XX-HP:
4 mils: 6.5-9.3 cm (2.5-3.6 in)
10 mils: 4.2-32.1 cm (1.6-12.6 in)
Max Resolution
b
b. 1D codes are Code 39 and 2D codes are Data Matrix
PM96XX:
1D = 3 mils, 2D = 6 mils
PM96XX-HP:
1D = 2.5 mils, 2D = 4 mils
PD96XX AND PM96XX DECODE CAPABILITY
1D Bar Codes
GS1 Databar linear codes, UPC/EAN (A,E,13,8), including P2/P5 Addons, ISBN ,ISSN,
Code128, EAN128, ISBT128, Code39, Code39 Full ASCII, Code39 CIP, Code 32, Trioptic,
Interleaved 2 of 5, IATA, Industrial 2 of 5, Standard 2 of 5, matrix2 of 5, datalogic 2 of 5, fol-
let 2 of 5, Codabar, Code11, MSI, Plessey, Code 93, Pharmacode, BC412
2D / Stacked Codes
DataMatrix (square, rettangular ), MaxiCode ,QR Codes,(QR, Micro QR and Multiple QR
codes), Aztec
Postal codes including: Australian Post, China Post, Japanese Post, KIX Post, Planet Code,
Postnet, Royal Mail Code(RM45CC), IMB, Sweden Post,Portugal Post, LaPoste A/R 39
Stacked codes including EAN/JAN Composites, GS1 Databar Composites, GS1 Databar
Expanded Stacked; GS1 DataBar Stacked; GS1 DataBar Stacked Omnidirectional, PDF417,
Macro PDF, Micro PDF417, China sensible, DotCode
Other
OCR, Digimarc
