SETUP
24
POWERSCAN™ PD/PM96XX
Connecting BC9680 cables
Connect the Ethernet cable and then connect the power adapter cable. Finally, power
on the cradle and lock the power cable on the strain relief.
To disconnect the cables, first unlock the power cable and then pull it out. To disconnect
the Ethernet cable, use a flat screwdriver to unlock the Ethernet clip.
CAUTION: Do not place two base stations too close to each other as shown
in the figure below. Keep at least 5cm of distance between them, in order
to avoid possible interferences and malfunction of the two wireless
charging systems.
