Getting Started
6 QuickScan
®
L
Setting Up the Scanner
Installing the Interface Cable
To connect the interface cable:
1. Insert the interface cable’s modular connector clip into the cable interface port on the bot-
tom of the scanner handle. (See Figure 1).
2. Gently tug the cable to ensure the connector is properly secured.
3. Connect the other end of the interface cable to the host. (See the specific host chapter for
information on host connections.)
Figure 1. Connecting the Interface Cable
NOTE
Specific cables are required for connection to different hosts. The
connectors illustrated in each host chapter are examples only. Actual
connectors may vary from those illustrated, but the steps to connect
the scanner remain the same.
Cable Clip (Latch)
To Host
Cable
Cable Strain Relief
Bottom of Scanner
Interface Cable Port

Datalogic QuickScan L QD 2300 Specifications

General

Brand	Datalogic
Model	QuickScan L QD 2300
Category	Barcode Reader
Language	English
