Keyboard Wedge Interface
64 QuickScan
®
L
Keyboard Maps
The following keyboard maps are provided for prefix/suffix keystroke parameters. To
program the prefix/suffix values, see the bar codes on
page 27 through page 29.
Figure 10. IBM PC/AT
Figure 11. IBM PS/2
ASCII Character Set for Keyboard Wedge
5001
5002
5003
5004
5005
5006
5007
5008
5009
5010
7009
7008
7013
7012
7004
7011
7003
7002
7014
NOTE
Code 39 Full ASCII interprets the bar code special character ($ + % /) preced-
ing a Code 39 character and assigns an ASCII character value to the pair. For
example, when Code 39 Full ASCII is enabled and a +B is scanned, it is inter-
preted as b, %J as ?, and %V as @. Scanning ABC%I outputs the keystroke
equivalent of ABC >.
Table 10. Keyboard Wedge ASCII Character Set
ASCII Value
Full ASCII
Code 39 Encode Character
Keystroke
1001 $A CTRL A
1002 $B CTRL B
1003 $C CTRL C
1004 $D CTRL D
1
The keystroke in bold is sent only if the “Function Key Mapping” is enabled. Otherwise, the
unbolded keystroke is sent.
