Standard Cable Pinouts
Product Reference Guide 149
Standard Cable Pinouts
Figure 13 and Table 29 provide standard pinout information for the scanner’s cable.
Figure 13. Standard Cable Pinouts
Pin 1
Pin 10
Cable Clip (Latch)
To Host
Cable
Cable Strain Relief
Bottom of Scanner
Interface Cable Port
