RS-232 Host Parameters
Product Reference Guide 39
Stop Bit Select
The stop bit(s) at the end of each transmitted character marks the end of transmission of
one character and prepares the receiving device for the next character in the serial data
stream. The number of stop bits selected (one or two) depends on the number the receiv-
ing terminal is programmed to accommodate. Set the number of stop bits to match host
device requirements.
Data Bits (ASCII Format)
This parameter allows the scanner to interface with devices requiring a 7-bit or 8-bit
ASCII protocol.
*1 Stop Bit
2 Stop Bits
7-Bit
*8-Bit
