Product Reference Guide 31
Chapter 6
RS-232
Introduction
This chapter describes how to set up the scanner with an RS-232 host. The RS-232 in-
terface is used to connect the scanner to point-of-sale devices, host computers, or other
devices with an available RS-232 port (e.g., com port).
If the host is not listed in Table 6, refer to the documentation for the host device to set
communication parameters to match the host.
Throughout the programming bar code menus, default values are indicated with asterisks
(*).
NOTE
The scanner uses TTL RS-232 signal levels, which will interface with most
system architectures.
*Baud Rate 57,600
Feature/Option
* Indicates Default
