Product Reference Guide 147
Appendix A
Technical Specifications
Table 28 contains Physical and Performance Characteristics, User Environment and
Regulatory information. Table 29 provides Standard Cable Pinouts.
Table 28. Technical Specifications
Item Description
Physical Characteristics
Dimensions
2.79 in. H x 6.71 in. L x 2.59 in. W
(7.09 cm H x 17.04 cm L x 6.69 cm W)
Weight (without cable) Approximately 4.5 oz. (128 g)
Voltage & Current
5.0 VDC +/-10%
Standby: <35mA
Operating: 100mA
Max: 175mA
Color Black or White
Performance Characteristics
Light Source (Laser) 650nm laser diode
Scan Rate 100 scans per second
Scan Width 47°
Roll (Tilt) Tolerance ± 30° from normal
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 60°
Typical DOF Distance
13 mil (100% UPC/EAN): 0 to 9 in. (22.86 cm)
5 mil (Code 39): 0.5 to 5.5 in. (1.27 cm to 13.97 cm)
(See
Depth of Field on page 14.)
Print Contrast Minimum 30% minimum reflectance
Decode Capability
UPC/EAN, UPC/EAN with Supplementals, UCC/EAN 128, Code 39,
Code 39 Full ASCII, Code 39 TriOptic, Code 128, Code 128 Full ASCII,
Codabar, Interleaved 2 of 5, Discrete 2 of 5, Code 93, MSI, Code 11,
IATA, GS1 DataBar (RSS) variants, Chinese 2 of 5
Interfaces Supported RS-232; Keyboard Wedge; USB
