150 QuickScan
®
L
The signal descriptions in Table 29 apply to the connector on the scanner and are for
reference only.
Table 29 Standard Cable Pinouts
Pin RS-232 Keyboard Wedge USB
1 RTS nc Jump to Pin 5
2 nc Clk In D+
3 nc Data In D-
4 Ground Ground Ground
5 RXD nc Jump to Pin 1
6 TXD nc nc
7 Power Power Power
8nc Clk Out nc
9nc Data Out nc
10 CTS nc nc
