INSTALLATION
5
2
Then fix the VSM on the panel using the two locking screws and the two rubber caps.
92
±0.2
[3.62
±0.01
]
92
±0.2
[3.62
±0.01
]
R7.5
[R0.30]
Locking screw
Cap
