M7/M7L/M7LT Modular Satellite Modem Maintenance
M7/M7L/M7LT - Rev. 0.05 3-45
Modulator Parameters
Representation
Type
Entry
Description
BUC Remote Parameter 3
(Future Option)
Numeric
Future Option
Event Carrier Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the Carrier
alarm.
Event AUPC Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the AUPC
alarm.
Event BUC Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the BUC
alarm.
Event BUC FSK Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the BUC FSK
alarm.
Event Minor Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
activity of any Minor alarms
Event Major Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
activity of any Major alarms
Event Test Active
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the status
of the Test Active alarm
Event Hardware Alarm
Log
Selection
1 = Log
2 = Log & Send Alert
Selects whether to set an alert
for the status of the Hardware
alarm
Alarm Carrier Mask
Mute & Alarm A
Selection
0-4= Mute CXR,
5 = Mute CXR & Alarm A,
6 = Mute CXR & Alarm B,
7 = Mute CXR & Alarm A & B
Selects destination of alarm
Alarm AUPC Mask
To Alarm B
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of alarm
Alarm Test Active Mask
To Alarm A
Selection
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
Selects destination of alarm
Alarm Hardware Mask
Mute & Alarm A
Selection
0-4= Mute CXR,
5 = Mute CXR & Alarm A,
6 = Mute CXR & Alarm B,
7 = Mute CXR & Alarm A & B
Selects destination of alarm
Alarm BUC Power Mask
to Alarm A
Selection
0=None, 1=A, 2=B, 3=A&B,
4 = Mute CXR,
5 = Mute CXR & Alarm A,
6 = Mute CXR & Alarm B,
7 = Mute CXR & Alarm A & B
Selects destination of alarm in
the M7LT.
Alarm BUC Voltage Min
+20.0 V
Numeric
