M7/M7L/M7LT Modular Satellite Modem Maintenance

M7/M7L/M7LT - Rev. 0.05 2-7

NOTE: The internal AC or DC BUC power supplies in the M7LT can be changed in the field by a

qualified operator. Figure 2-6 shows the location of the BUC power supply in the AC input

power unit and Figure 2-7 shows the location of the BUC power supply in the DC input unit.

Instructions on how to acquire and install a different BUC power supply can be found in an

Application Note.

Figure 2-6 – M7LT Internal BUC Power Supply (AC version shown)

Figure 2-7 – M7LT Internal BUC Power Supply (DC Version)

Location of the Internal BUC Power Supply

(AC Prime Power input / -48VDC output)

Location of the Internal BUC Power Supply

(DC Prime Power input / -48VDC output)
