G7 Interface Parameters
Representation
Type
Entry
Description
Event Test Active
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the status
of the Test Active alarm
Event Hardware Alarm
Do Not Log
Selection
1 = Log
2 = Log & Send Alert
Selects whether to set an alert
for the status of the Hardware
alarm
Alarm I/O Port 1 Mask
to Alarm A
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of Port 1
alarm
Alarm I/O Port 2 Mask
to Alarm A
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of Port 2
alarm
Alarm Backward Mask
to Alarm A
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of alarm
Alarm Test Active Mask
to Alarm A
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of alarm
Alarm Hardware Mask
to Alarm A & B
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of alarm
Feature Options
None
Read Only
N/A
Feature Activation
00000000000000000000
Numeric
20 characters
Allows entry of a Feature code to
activate new features.
Table 3-12 – High Speed Serial Interface (HSSI) Parameter Detail
High Speed Serial Interface Parameters
Representation
Type
Entry
Description
Status I/O
Online
Read Only
N/A
Interface Status
Status Send Clock
Locked, Ok
Read Only
N/A
Status Send Data
Active, Ok
Read Only
N/A
Status Rcv Buffer
100%, 0 Slips
Read Only
and Reset
Press “1” then "Enter" to
re-center the buffer.
Press “0” then "Enter" to
clear the “Slip Status”.
Only shows if the Rcv Buffer is
active. 100% is buffer center.
Status Rcv Data
Active, Ok
Read Only
N/A
Status I/O Signaling
ta CA
Read Only
N/A
HSSI signaling status. Lower
case indicates not-active status,
upper case indicates active
status
