E7 Interface Parameters
Representation
Type
Entry
Description
Alarm IO Mask
Mute & Alarm A & B
Selection
0=None, 1=A, 2=B,
3=A&B, 4 = Mute CXR,
5 = Mute CXR & Alarm A,
6 = Mute CXR & Alarm B,
7 = Mute CXR & Alarm A
& B
Selects destination of alarm
Alarm Send Data Mask
to Alarm A
Selection
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
Selects destination of alarm
Alarm Send Data Idle
30 Sec.
Numeric
0000 to 9999 Sec
Sets the time before an alarm is
raised after there is no data
detected at the Tx interface. (0 =
Disable)
Alarm Rcv Data Mask
to Alarm A
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of alarm
Alarm Rcv Data Idle
30 Sec.
Numeric
0000 to 9999 Sec
Sets the time before an alarm is
raised after there is no data
detected at the Rcv interface. (0
= Disable)
Alarm Ref Relay Mask
to Alarm A
Selection
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
(Future Option) Selects
destination of alarm
Alarm Test Active Mask
to Alarm A
Selection
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
Selects destination of alarm
Alarm Hardware Mask
to Alarm A
Selection
0=None, 1=to Alarm A,
2=to Alarm B,
3=to Alarm A & B
Selects destination of alarm
Test Sat WAN Loopback
Disabled
Selection
0 = Disabled, 1 = Enabled
Interface satellite loop-back
receive output to send input
Test Ter WAN Loopback
Disabled
Selection
0 = Disabled, 1 = Enabled
Interface terrestrial loop-back
send input to receive output.
Feature Options
None
Read Only
N/A
Feature Activation
00000000000000000000
Numeric
20 characters
Allows entry of a Feature code to
activate new features.
Table 3-11 – G7 – Dual G.703/E1 Interface Parameter Detail
G7 Interface Parameters
Representation
Type
Entry
Description
Status I/O
Online, OK
Read Only
N/A
Interface Status
Status I/O Port 1
Normal
Read Only
N/A
Port 1 Interface Status
