E7 Interface Parameters
Representation
Type
Entry
Description
MCC Mode
Full Access
Selection
0 = Disable
1 = Read Only
2 = Full Access
Sets the rights of the MCC
channel.
MCC Protocol
M7 Binary Packet
Selection
0 = M7 Binary Packet
MCC Send Rate Limit
10.0 kbps
Numeric
Entered in kbps up to the
maximum rate of the
satellite data rate.
Sets the maximum rate of the
MCC channel
MCC Send Address
1
Numeric
1 to 254, 255 is a
broadcast address
Sets the address of the Send
MCC port
MCC Rcv Address
1
Numeric
1 to 254, 255 is a
broadcast address
Sets the address of the Rcv MCC
port
MCC Activity
1
Selection
0 = None
1 = Beep
2 = Blink Online Lamp
3 = Beep & Blink Online
Sets the notification when there
is MCC traffic detected.
Ref Relay Mode
Output
Selection
0 = Disable, 1 =
Future Option
Ref Relay Frequency
2.048 MHz
Numeric
Future Option
Event I/O Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the IO alarm
Event Send Data Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the Send
Data alarm
Event Rcv Data Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the Rcv Data
alarm
Event Ref Relay Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
(Future Option) Selects whether
to log the change in status of the
Ref Relay alarm
Event Minor Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the activity
of any Minor alarms
Event Major Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the activity
of any Major alarms
Event Test Active
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the status
of the Test Active alarm
Event Hardware Alarm
Do Not Log
Selection
1 = Log
2 = Log & Send Alert
Selects whether to set an alert
for the status of the Hardware
alarm
