Synchronous Interface Parameters
Representation
Type
Entry
Description
Test BER EFS
94.35%
Read Only
Enter to restart test
Error free seconds in the active
test measurement if ‘Test Rcv
BER’ is active
Test BER Erred Sec
15
Read Only
Enter to restart test
Errored seconds in the active test
measurement if ‘Test Rcv BER’ is
active
Test BER Total Sec
8485
Read Only
Enter to restart test
Total seconds in the active test
measurement if ‘Test Rcv BER’ is
active
Test Send Bit Offset
0 PPM
Read Only
N/A
Monitor of the frequency offset of
the incoming bit clock reference
to the internal modem reference
standard.
Test Rcv Bit Offset
0 PPM
Read Only
N/A
Monitor of the frequency offset of
the bit clock recovered from the
satellite, reference to the internal
modem reference standard.
Feature Options
None
Read Only
N/A
Feature Activation
00000000000000000000
Numeric
20 characters
Allows entry of a Feature code to
activate new features.
Table 3-9 – I7 - IP Interface Parameter Detail
I7 Interface Parameters
Representation
Type
Entry
Description
Status IP
Online, OK
Read Only
N/A
Interface Status
Status GbE
Connected, 1 Gb
Read Only
N/A
Interface Mode Status
Status Ref Relay
Locked, OK
Read Only
N/A
Future Option
Status Send Data
Active, Ok
Read Only
N/A
Send Data Activity Status
Status Rcv Data
Active, Ok
Read Only
N/A
Rcv Data Activity Status
Status Test
Normal
Read Only
N/A
Interface Test status
Status Hardware I/O Opt
Remote Ref Relay
Read Only
N/A
Status Hardware IP Opt
IP Accelerator
Read Only
N/A
Status Hardware Type
I7 IP Interface
Read Only
N/A
Indicates the type of the active
interface
Status Hardware ID
M709018A-1r0
Read Only
N/A
Indicates the part number of the
active interface
