Datum Systems M7 Series - Page 124

Maintenance M7/M7L/M7LT Modular Satellite Modem
3-68 M7/M7L/M7LT - Rev. 0.05
G7 Interface Parameters
Representation
Type
Entry
Description
Status I/O Port 2
Normal
Read Only
N/A
Port 2 Interface Status
Status I/O Port 1 Rcv Buffer
100%, 0 Slips
Read Only
and Reset
Press “Edit” then "Enter"
to re-center the buffer.
Only shows if the Rcv Buffer is
active. 100% is buffer center.
Status I/O Port 2 Rcv Buffer
100%, 0 Slips
Read Only
and Reset
Press “Edit” then "Enter"
to re-center the buffer.
Only shows if the Rcv Buffer is
active. 100% is buffer center.
Status ESC Signaling
RTS CTS DCD DTR DSR
Read Only
N/A
Interface ESC signaling status.
Lower case indicates not-active
status, upper case indicates
active status. Only shown when
the ESC channel is active.
Status Test
BER Active
Read Only
N/A
Interface Test status
Status Hardware Type
Dual G703 Interface
Read Only
N/A
Indicates the type of the active
interface
Status Hardware ID
M709014A-100r1.00
Read Only
N/A
Indicates the part number of the
active interface
Status Hardware S/N
100048
Read Only
N/A
Indicates the serial number of the
active interface
I/O Port 1 Mode
E1 Balanced 120 Ohm
Selection
0 = Disable
1 = E1 Balanced 120
Ohm
2 = E1 Unbalanced 75
Ohm
Interface Port 1 electrical mode.
I/O Port 1 Send Coding
HDB3
Selection
0 = AMI, 1 = HDB3
Sets the line coding of the Port 1
E1 Send Data
I/O Port 1 Send Framing
Full E1
Selection
0 = Full E1
Sets the Framing of the Port 1 E1
Send Data
I/O Port 1 Send Nx64
2048.000 kbps
Numeric
64.000 to 2048.000 kbps
in 64 kbps steps. If Send
Framing is set to Full E1,
2048.000 is the only
setting
Sets the Interface Port 1 Send
data rate
I/O Port 1 Rcv Coding
HDB3
Selection
0 = AMI, 1 = HDB3
Sets the line coding of the Port 1
E1 Rcv Data
I/O Port 1 Rcv Framing
Full E1
Selection
0 = Full E1
Sets the Framing of the Port 1 E1
Rcv Data
I/O Port 1 Rcv Nx64
2048.000 kbps
Numeric
64.000 to 2048.000 kbps
in 64 kbps steps. If Rcv
Framing is set to Full E1,
2048.000 is the only
setting
Sets the Interface Port 1 Rcv
data rate
