Synchronous Interface Parameters
Representation
Type
Entry
Description
MCC Send Address
1
Numeric
1 to 254, 255 is a
broadcast address
Sets the address of the Send
MCC port
MCC Rcv Address
1
Numeric
1 to 254, 255 is a
broadcast address
Sets the address of the Rcv MCC
port
MCC Activity
1
Selection
0 = None
1 = Beep
2 = Blink Online Lamp
3 = Beep & Blink Online
Sets the notification when there
is MCC traffic detected.
Event Send Clock Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the Send
Clock activity alarm
Event Send Data Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the Send
Data activity alarm
Event Rcv Data Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the Rcv Data
activity alarm
Event Backward Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the Backward
alarm
Event BER Loss Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the BER Loss
alarm
Event Buffer Slip
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the
change in status of the Buffer
Slip alarm
Event Minor Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the activity
of any Minor alarms
Event Major Alarm
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the activity
of any Major alarms
Event Test Active
Do Not Log
Selection
0 = Do Not Log
1 = Log
2 = Log & Send Alert
Selects whether to log the status
of the Test Active alarm
Event Hardware Alarm
Do Not Log
Selection
1 = Log
2 = Log & Send Alert
Selects whether to set an alert for
the status of the Hardware alarm
Alarm Send Clock Mask
to Alarm A
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of alarm
Alarm Send Data Mask
to Alarm A
Selection
0 = None, 1 = to Alarm A,
2 = to Alarm B,
3 = to Alarm A & B
Selects destination of alarm
