DaVinci fireplace - Installation Procedures; Packing List and Required Equipment

Installation (for qualified installers only) 13
© Travis Industries 4150126 100-01418
Packing List for Fireplace Modules
Included Hardware (for Set & Vent)
ITEM Qty Location Notes
Manual 1 You’re looking at it baby!
On-Off LED Harness (8
wires)
1 Hardware Box 10, 25, or 50 Length
On/Off Switch 1 Hardware Box
LED Controller 1 Hardware Box Labeled “Elemental LED”
Double-Gang Junction
Box
1 Hardware Box
Double-Gang Cover
Plate
1 Hardware Box
Exhaust Blower
Assembly (B)
1
On its own pallet Low Volume 94400903 (B)
High Volume 94400904 (B)
Tension Rods
Lock-tied to top of fireplace
Addtitional Equipment Required (for Set & Vent)
ITEM REQUIRED WHERE SHIPPED SKU
Suction Cups For
Glass
Yes
Ordered separately 94400914 (includes 2 suction cups)
Fireback Liners
(see “Firebacks” on
page 69 for qty.)
Yes In its own box
Gloss Black Enamel
Silver Painted
Matte Black Painted
Exhaust Damper
Wiring Harness
Yes
? 50 Foot 94700887
150 Foot 94700888
250 Foot 94700889
10” B-Vent Yes
In its own box(s) 36” Section 98900060
18” Section 98900061
90° Elbow 98900062
45° Elbow 98900063
12” Adjustable Section 98900064
Wall Strap 98900065
Fire Stop 98900066
Optional Intake
Damper(s)
(A) Hardware Box
Hori w Term 6” (98900093)
Hori w Term 8” (98900094)
Inline Dmpr 6” (98900078)
Inline Dmpr 8” (98900079)
Air Intakes (6” or 8” Dia.) (A)
Intake Wiring Harness (if
using intake damper)
(A) Hardware Box 25’ Length (Black and
White Wire)
(A) Refer to the dimensions page of your fireplace to determine the number of intakes required.
(B) Refer to the dimensions page of your fireplace to determine the type of power exhaust required.
Finalization Hardware (install after fireplace is in place – you may hold at dealership)
ITEM Location Notes
Crushed Glass Hardware Box Center Channel uses 1.5 Lbs.
(cups) per foot
Outer Channel uses 1 Lbs.
(cups) per foot
