Installation (for qualified installers only) 73
© Travis Industries 4150126 100-01418
Glass Pane Installation and Removal
This fireplace uses a dual layer of glass to provide combustion air to the fireplace and keep the exterior
cool. The glass panes are packaged separately and do not use a steel glass frame.
The appliance must be completely cool before removing the glass.
Do not strike or slam the glass.
Warning: Do not operate appliance with the glass front removed, cracked or broken.
Replacement of the glass should be done by a licensed or qualified service person.
Use only glass provided by Travis Industries for this appliance. Do not use substitute
glass.
Suction Cups
NOTE: Suction cups are required for glass installation and removal. These are available from Travis
Industries (sku 94400914).
When to Install the Glass Panes
The glass is typically installed after all other steps have been completed. This helps ensure the glass is
kept clean and away from potential damage.
(a) Fireplace should be in location and attached to power, gas, vent and intake.
(b) Install the firebacks.
(c) Install the inner glass and test-start the fireplace. This is done to verify appliance
operation only. Do not let the appliance burn for more than 5 minutes.
(d) Remove the front inner glass.
(e) Install the crushed glass over the burner and inner media trays.
(f) Replace the front inner glass.
(g) On Pier, Bay, and Island models, install the side outer glass panes.
(h) If crushed glass is being used in the intake air channel, install it at this time.
(i) Install the remaining outer glass panes.
Overview of Glass Panes – Category 2 Fireplaces
Type of Fireplace
# of Glass Panes Glass Sizing
1-Sided 2 TBD
Pier 6 TBD
Full Bay 6 TBD
Island 8 TBD
2-Sided 4 TBD
Check for the DaVinci Logo Before Installing the Glass
The outer piece of glass has a DaVinci logo. Make sure it is on the lower right and is facing outwards.
