DaVinci fireplace - Page 63

Installation (for qualified installers only) 63
© Travis Industries 4150126 100-01418
Power Exhaust Dimensions – High Volume (RS16) 94400904
2.625"
67mm
16"
407mm
3"
76mm
8.625"
220mm
14.125"
359mm
25"
635mm
26.25"
667mm
13.125"
334mm
26.75"
680mm
29.75"
756mm
27.5"
699mm
21.625"
550mm
3"
76mm
(centered)
