Installation (for qualified installers only) 75
© Travis Industries 4150126 100-01418
Installing the Glass Panes Into the Fireplace
Before installing the glass, make sure to measure it to verify it is the correct piece. Refer to the section
“When to Install the Glass” on page 73 to determine when to install the glass.
(a) Before installing the glass pane, verify the lower channel is free of crushed glass or any other
debris. Any debris left in this channel will cause an air lead and may damage the glass pane.
(b) Lift the glass pane and insert it at an angle so the top edge inserts into the upper slot.
(c) Swing the lower edge of the glass pane inwards until the lower edge can insert into the lower slot.
