DriveRack™ User Manual
ii
DriveRack
™
Congratulations on your purchase of the dbx 240/241DriveRack™ Complete Equalization and
Loudspeaker Management System! For over 25 years, dbx has been the industry leader in
dynamics processing. With the introduction of the DriveRack™, dbx Professional Products has
redefined the standard by which all other loudspeaker management systems will be based.
This manual will be your guide to understanding the full functionality of the powerful 240 and
241 DriveRack™ units. By combining the different components, the configuration possibilities
are limitless. After you have become familiar with the unit, we encourage you to experiment
and find the most effective and efficient way to run your system by utilizing the powerful pro-
cessing of the DriveRack™.
The dbx 240/241 DriveRack™ is the most effective way to manage all aspects of post mixer pro-
cessing and signal routing. The 240/241 DriveRack essentially becomes the only device that you
will need between the mixer and the power amps. The following are just some of the features
of the 240 and 241 DriveRack™ units.
240 DriveRack™ features:
• 2 Inputs and 4 Outputs
• Fully functional user interface
• Balanced XLR and Euroblock Connectors
• 31-band graphic or 9-band parametric equalizer on every input
• Multiple Crossover Configurations including Butterworth, Bessel or Linkwitz-Riley
filter topologies
• Loudspeaker Cluster and Transducer Alignment Delays
• 4-band Parametric EQ Post crossover per output. Selectable shelves or bell curves.
1/12 octave centers, Q selectable from 0.20 to 16.
• dbx
®
Compression/Limiting
• Multi-level Security System
• Patented dbx
®
TYPE IV
®
Analog to Digital Conversion System
• PC DriveWare Interface
• Remote Switch Closure Interface
241 DriveRack™ features:
• 2 Inputs and 4 Outputs
• Balanced XLR and Euroblock Connectors
• 31-band graphic or 9-band parametric equalizer on every input
• Multiple Crossover Configurations including Butterworth, Bessel or Linkwitz-Riley
filter topologies
• Loudspeaker Cluster and Transducer Alignment Delays
• 4-band Parametric EQ Post crossover per output. Selectable shelves or bell curves.
1/12 octave centers, Q selectable from 0.20 to 16.
0.1 Defining the 240/241 DriveRack™ System
INTRODUCTION
