dbx DriveRack 240 - Flash Downloads; Program List

®
The 240 and 241 DriveRack™ units have the ability to update their operating systems (OS) with the latest version avail-
able via the Internet. In order to perform a flash download your PC must be able to receive/transmit information through
the RS-232 connector. The Flash download procedure is as follows:
1. Connect the RS 232 output from your PC to the RS 232 port of the DriveRack™.
2. Access the World Wide Web.
3. Go to www.dbxpro.com to access the latest OS version.
4. Download the latest OS version and all attached software.
5. Follow the detailed instructions from the website.
Start Flash Download Session (Front Panel 240)
• Press and hold the PREV PAGE button on power-up until the following message appears:
"WAITING FOR FLASH DOWNLOAD"
At this point, follow the flash download instructions to perform a flash download. It is always recommended that a
sof preset be performed after a flash download.
Start Flash Download Session (Front Panel 241)
Press and hold the UP and LOAD buttons on power-up until the following message appears:
"FL"
• At this point follow the flash download instructions to perform a flash download.
U1)2Way w/GEQ F1) 2Way w/GEQ
U2) LR w/Delay F2) LR w/Delay
U3) Mono LCR w/Sub F3) Mono LCR w/Sub
U4) Zones with filter F4) Zones with filter
U5) LR w/Dual Sub F5) LR w/Dual Sub
U6) Bi-Amp Monitors F6) Bi-Amp Monitors
U7) Delay Speakers F7) Delay Speakers
U8) 2 Channel GEQ F8) 2 Channel GEQ
U9) 2 Channel PEQ F9) 2 Channel PEQ
U10) LR w/Sub & Aux F10) LR w/Sub & Aux
U11) Array 4890-91 F11) Array 4890-91
U12) Array 4892-45S F12) Array 4892-45S
U13) HLA 12 & 6 F13) HLA 12 & 6
U14) HLA 6 & 4 F14) HLA 6 & 4
U15) SP 215-9 F15) SP 215-9
U16) SP 222 F16) SP 222
U17) SR 4731X w/Sub F17) SR 4731X w/Sub
U18) SR 4732X w/Sub F18) SR 4732X w/Sub
U19) VS 3215-6 F19) VS 3215-6
U20) VS 3215-9 F20) VS 3215-9
A.4 Program List
A.3 Flash Downloads
Appendix A
DriveRack
™
DriveRack™ User Manual
51
