HIGH ENGINE TEMPERATURE if the module detects that the engine coolant temperature has exceeded the high
engine temperature pre-alarm setting level after the Safety On timer has expired, a warning will occur.
The
icon will illuminate.
OVERSPEED, if the engine speed exceeds the pre-alarm trip a warning is initiated.
The
icon will illuminate.
Overspeed is not delayed, it is an immediate warning.
UNDERSPEED, if the engine speed falls below the pre-set pre-alarm after the Safety On timer has expired, a
warning is initiated.
The
icon will illuminate.
GENERATOR HIGH FREQUENCY if the module detects a generator output frequency in excess
of the pre-set pre-alarm, a warning is initiated.
The
icon will illuminate.
Generator High Frequency is not delayed, it is an immediate warning.
GENERATOR LOW FREQUENCY, if the module detects a generator output frequency below the
pre-set pre-alarm after the Safety On timer has expired, a warning is initiated.
The
icon will illuminate.
GENERATOR HIGH VOLTAGE if the module detects a generator output voltage in excess of the pre-set trip a
shutdown is initiated.
The
V
icon will illuminate.
High voltage is not delayed, it is an immediate shutdown.
GENERATOR LOW VOLTAGE if the module detects a generator output voltage below the below the pre-set pre-
alarm after the Safety On timer has expired, a warning is initiated.
The
V
icon will illuminate.
CAN ECU ERROR If the module is configured for J1939 operation and receives an “error” message from
the engine control unit, ‘Can ECU fail” is shown on the module’s display and a warning alarm is generated.
Usually, an associated alarm code is also displayed, detailing the exact alarm detected. For details on
these code meanings, refer to the ECU instructions provided by the engine manufacturer.
4.3 HIGH CURRENT WARNING ALARM
GENERATOR HIGH CURRENT, if the module detects a generator output current in excess of the pre-set trip a
warning is initiated.
The
A
icon will illuminate.
If this high current condition continues for an excess period of time, then the alarm is escalated to a shutdown
condition. For further details of the high current alarm, please see High Current Shutdown Alarm.
