DSE Model 5210 Automatic Start Engine Management and Instrumentation System Operators Manual
13 FACTORY DEFAULT CONFIGURATION
In the tables below, the icon
# indicates an item that can be adjusted from the module’s front panel editor.
Absence of the # icon beside an item means that adjustment of this parameter is only possible using the 5200
series configuration software in conjunction with the P810 interface.
For further details on adjustment from the front panel editor, see the section entitled “Front panel configuration”
elsewhere within this manual.
5200 series configuration software. Configuration for 5210 module.
Filename – 5210a.XCF
Printed on 14/04/03 12:25:18
Module settings Value
Base module 5210 remote start module
Miscellaneous settings Value
Alternator fitted Yes
Poles 4
Magnetic pickup fitted No
J1939 enabled No
AC System 3 phase, 4 wire
Enable fast loading feature No
Number of start attempts 3
Input settings - Analogue Value
Low oil pressure input type VDO 10 bar
High coolant temp input type VDO 120 degrees C
Trip Return
Low oil pressure pre-alarm
#
1.17 Bar 17.0 PSI 1.24 Bar 18.0 PSI
Low oil pressure shutdown
#
1.03 Bar 14.9 PSI N/A
High coolant temp pre-alarm
#
115°C 239°F 110°C 230°F
High coolant temp shutdown
#
120°C 248°F N/A
Fuel level input type VDO Ohm Range
Fuel pump control No
Low fuel level
#
10%
Input settings - Digital Value
1 Remote start Close to activate
2 User configured Close to activate, Indication Always active
3 User configured Close to activate, Warning Active from safety on
4 User configured Close to activate, Shutdown Always active
5 User configured Close to activate, Shutdown Active from safety on
6 User configured Close to activate, Electrical trip Always active
LCD indicator settings Value
1 Lit Remote start present
2 Lit Digital input 2 active
3 Lit System in auto mode
4 Lit Common alarm
Output settings – Relay Value
1 Energise Preheat (during pre-heat timer)
2 Energise Common alarm
3 Energise Close generator
43
