Deep Sea Electronics Plc 5210

DSE Model 5210 Automatic Start Engine Management and Instrumentation System Operators Manual
8.2.3 PLUG “C” 3 WAY (OPTIONAL, FITTED TO J1939 CONTROLLERS ONLY)
PIN
No
DESCRIPTION
20 CanBus port Common. Do not connect this terminal to earth. Use only screened
120Ω cable approved specifically for use in CanBus applications.
21
CanBus port H. Use only screened 120Ω cable approved specifically for use in
CanBus applications.
22
CanBus port L. Use only screened 120Ω cable approved specifically for use in
CanBus applications.
8.2.4 PLUG “D” 4 WAY (OPTIONAL, FITTED TO RS485 CONTROLERS ONLY)
PIN
No
DESCRIPTION
23 RS485 port Common
24
RS485 port B. Use only screened 120Ω cable approved specifically for use in RS485
applications.
25
RS485 port A. Use only screened 120Ω cable approved specifically for use in RS485
applications.
26 Not used. Do not connect to this terminal.
NOTE:- Connector E is not fitted to the 5210 remote start module.
8.2.5 PLUG “F” 4 WAY
PIN
No
DESCRIPTION
35 Generator L1 sensing input. Connect to alternator L1 output.
36 Generator L2 sensing input. Connect to alternator L2 output. If using single phase
only do not connect this terminal.
37 Generator L3 sensing input. Connect to alternator L3 output. If using single phase
only do not connect this terminal.
38 Generator N sensing input. Connect to alternator N output.
8.2.6 PLUG “G” 5 WAY
PIN
No
DESCRIPTION
39 Generator L1 current transformer connection.
40 Generator L2 current transformer connection. If single phase is used do not
connect this pin.
41 Generator L3 current transformer connection. If single phase is used do not
connect this pin.
42 Generator current transformer common connection and CT earth connection.
43 Not used. Do not connect to this terminal.
5210 OPERATING MANUAL ISSUE 2 21/05/2003 AM 32
