DSE Model 5210 Automatic Start Engine Management and Instrumentation System Operators Manual
8.3.4 SCANIA S6
PLUG “A” 8 WAY
52xx
PIN No
52xx
DESCRIPTION
Scania EMS B1 connector NOTES
4 Fuel relay output 3 Ignition U15
5 Start relay output - Connects directly to engine starter
solenoid.
PLUG “C” 3 WAY
52xx
PIN No
52xx
DESCRIPTION
Scania EMS B1 connector NOTES
20 CANbus common - Screen for the J1939 cable. Connect at
52xx end only.
21 CANbus H 9
J1939 + Use only screened 120Ω
impedance cable approved specifically
for use in CANbus applications.
22 CANbus L 10
J1939 - Use only screened 120Ω
impedance cable approved specifically
for use in CANbus applications.
37
