8.3.2 JOHN DEERE
PLUG “A” 8 WAY
52xx
PIN No
52xx
DESCRIPTION
John Deere 21-pin Deutsch
connector
NOTES
4 Fuel relay output G, J G = Switched ECU power, J = Ignition
5 Start relay output D Start
PLUG “C” 3 WAY
52xx
PIN No
52xx
DESCRIPTION
John Deere 21-pin Deutsch
connector
NOTES
20 CANbus common - Screen for the J1939 cable. Connect at
52xx end only.
21 CANbus H V
J1939 + Use only screened 120Ω
impedance cable approved specifically
for use in CANbus applications.
22 CANbus L U
J1939 - Use only screened 120Ω
impedance cable approved specifically
for use in CANbus applications.
