14 ICONS AND LCD IDENTIFICATION
14.1 PUSH BUTTONS
Display Description Display Description Display Description
Stop/Reset
Auto mode
Manual mode
Configure / log
I
Start (when in
manual mode)
Scroll
14.2 STATUS / MEASUREMENT UNITS
Display Description Display Description Display Description
L1
Phase
L2
Phase
L3
Phase
Phase - Neutral Phase - Neutral
L3- N
Phase -Neutral
L1- L2
Phase - Phase
L2- L3
Phase - Phase
L3- L1
Phase - Phase
BAR
Pressure
KPa
KPa Oil Pressure
Units
PSI
Pressure
V
Voltage
o
F
Temperature
Hz
Frequency
A
Amperes
o
C
Temperature
RPM
Speed
kW
KiloWatts
kVA
Apparent power
KW divided by
kVA
¤
Hours Run AC
Generator
Timer in progress
DC
)
Factory (load)
#
Configuration
mode active
Fuel level
Event log
Panel locked by
configurable input
Canbus J1939
messages
L1- N L2- N
14.3 ALARM INDICATIONS
Display Description Display Description Display Description
Warning Alarm
Shutdown Alarm
Electrical Trip
Fuel
Low Oil Pressure
A
High Current
Warning
Charge Fail
High Coolant
Temperature
V
Over Voltage (AC)
Emergency Stop
Fail to start (Over-
crank)
V
Under Voltage
(AC)
V
Over Voltage (DC)
Over-speed
Over frequency
V
Under Voltage
(DC)
Under-speed Under frequency
Auxiliary
Indication
!
Auxiliary Alarm
(Warning or Shutdown)
