DSE Model 5210 Automatic Start Engine Management and Instrumentation System Operators Manual
1 INTRODUCTION
The DSE 5210 autostart module has been designed to allow the OEM to meet most of the industry’s complex
specifications. It has been primarily designed to allow the user to start and stop the generator, and if required,
transfer the load to the generator either manually (via external push-buttons) or automatically. The user also has
facility to view all the system operating parameters via the LCD display.
The DSE 5210 module monitors the engine, indicating the operational status and fault conditions; automatically
shutting down the engine and giving a true first up fault condition of an engine failure by a flashing COMMON
ALARM LED. Exact failure mode information is indicated by the LCD display on the front panel.
The powerful Microprocessor contained within the module allows for a range of complex features to be
incorporated as standard;
• Graphical Icon based LCD display (excluding the need for translations and languages).
• Voltage, Current and Power monitoring.
• Engine parameter monitoring.
• Fully configurable inputs for use as alarms or a range of different functions.
• Extensive range output functions using built in relay outputs or relay expansion available.
Selective operational sequences, timers and alarm trips can be altered by the customer via a PC using the 5200
series configuration software and P810 interface.
Access to critical operational sequences and timers for use by qualified engineers, are barred by a security code.
The module is housed in a robust plastic case for front panel mounting. Connections to the module are via locking
plug and sockets.
2 CLARIFICATION OF NOTATION USED WITHIN THIS PUBLICATION.
NOTE:
Highlights an essential element of a procedure to ensure
correctness.
CAUTION!
Indicates a procedure or practice which, if not strictly observed,
could result in damage or destruction of equipment.
WARNING!
Indicates a procedure or practice, which could result in injury to
personnel or loss of life if not followed correctly.
Deep Sea Electronics Plc owns the copyright to this manual, which
cannot be copied, reproduced or disclosed to a third party without
prior written permission.
Compliant with BS EN 60950 Low Voltage Directive
Compliant with BS EN 50081-2 EMC Directive
Compliant with BS EN 50082-2 EMC Directive
Indicates a function only applicable when the controller is
configured for connection to a J1939 engine controller
Year 2000 Compliant
5
