DSE Model 5210 Automatic Start Engine Management and Instrumentation System Operators Manual
Output settings – Expansion A Value
1 Energise Output not used
2 Energise Output not used
3 Energise Output not used
4 Energise Output not used
5 Energise Output not used
6 Energise Output not used
7 Energise Output not used
8 Energise Output not used
Timer settings Value
Start delay
#
5s
Pre-heat
#
0s
Sensor fail delay 2.0s
Cranking time
#
10s
Crank rest time
#
10s
Smoke limit 0s
Smoke limit off 0s
Safety on delay
#
10s
Overspeed overshoot
#
0s
Warming up time
#
0s
Transfer time 0.7s
Breaker close pulse 0.0s
Breaker trip pulse 0.0s
Return delay
#
30s
Cooling time
#
30s
ETS solenoid hold
#
0s
Fail to stop delay 30s
Generator transient
delay
1s
Battery low volts delay 1m
Battery high volts delay 1m
LCD page timer 5m
Generator settings – Voltage/frequency Trip Return
Under volts trip
#
184V AC N/A
Under volts pre-alarm
#
196V AC 207V AC
Over volts pre-alarm
#
265V AC 253V AC
Over volts trip
#
276V AC N/A
Under frequency trip
#
40.0 Hz N/A
Under frequency pre-alarm
#
42.0 Hz 45.0 Hz
Over frequency pre-alarm
#
55.0 Hz 52.0 Hz
Over frequency trip
#
57.0 Hz N/A
Generator settings – Current/power Value
Generator CT primary 500 A
Generator full load rating 500 A
Delayed overcurrent
#
100% ( 500 A )
Trip Curve 36
5210 OPERATING MANUAL ISSUE 2 21/05/2003 AM
44
