DeLaval MPCII User Manual

Installation
MPCII/Tandem
94381001.pdf2006-07-20
MPCII/Tandem
Installation
MPCII connections
Entrance Exit
Cow traffic
Special address: 90
Address:
No.
No.
Address:
Left parlour side
Right parlour side
A B
84 83 82 81 80
89 88 87 86 85
Left 5 L4 L3 L2 L1
Right 5 R4 R3 R2 R1
A = Left gate
B = Right gate
The address settings above are for a 2x5
parlour. Start with address 80 on the MPCII
nearest exit on left side (L1). Set the
address for the special MPCII after the
other, in this example address 90.
35(94)
