MPCII connections
The MPCIIs are connected in 3 different
ways depending on which cow place they
are installed at:
• with basic functions
• with gate valve and gate button
• with gate valve and gate switch
No. L7 L6 L5 L4 L3 L2 L1
No. R7 R6 R5 R4 R3 R2 R1
Cow traffic
Entrance Exit
MPC Type See sectionMPC Type See section
L1 With gate valve or gate switch "MPCII with MM15 and Gate valve or Gate
switch"
L1 With gate valve or gate switch "MPCII with MM15 and Gate valve or Gate
switch"
L2-L6 Basic functions "MPCII with MM15 and Basic functions"L2-L6 Basic functions "MPCII with MM15 and Basic functions"
L7 With gate valve and gate button "MPCII with MM15 and Gate valve and
Gate button"
L7 With gate valve and gate button "MPCII with MM15 and Gate valve and
Gate button"
39(94)
