● NVDIMM-Ns or RDIMMs must not be mixed with LRDIMMs.
● DDR4 NVDIMM-Ns must be populated only on the black release tabs on processor 1 and 2.
● All slots on configurations 3, 6, 9, and 12 can be used, but a maximum of 12 NVDIMM-Ns can be installed in a system.
NOTE: NVDIMM-N memory slots are not hot-pluggable.
For more information about the supported NVDIMM-N configurations, see the NVDIMM-N User Guide at www.dell.com/
poweredgemanuals.
Table 5. Supported NVDIMM-N for dual processor configurations
Configuration Description Memory population rules
RDIMMs NVDIMM-N
Configuration 1 12x 16 GB RDIMMs, 1x
NVDIMM-N
Processor1 {A1, 2, 3, 4, 5, 6}
Processor2 {B1, 2, 3, 4, 5, 6}
Processor1 {A7}
Configuration 2 12x 32 GB RDIMMs, 1x
NVDIMM-N
Same for all 12x RDIMM
configurations. See
Configuration 1.
Processor1 {A7}
Configuration 3 23x 32 GB RDIMMs, 1x
NVDIMM-N
Processor1 {A1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11, 12}
Processor2 {B1, 2, 3, 4, 5, 6,
7, 8, 9, 10, 11}
Processor2 {B12}
Configuration 4 12x 16 GB RDIMMs, 2x
NVDIMM-Ns
Same for all 12x RDIMM
configurations. See
Configuration 1.
Processor1 {A7}
Processor2 {B7}
Configuration 5 12x 32 GB RDIMMs, 2x
NVDIMM-Ns
Same for all 12x RDIMM
configurations. See
Configuration 1.
Processor1 {A7}
Processor2 {B7}
Configuration 6 22x 32 GB RDIMMs, 2x
NVDIMM-Ns
Processor1 {A1, 2, 3, 4, 5, 6, 7,
8, 9, 10, 11}
Processor2 {B1, 2, 3, 4, 5, 6,
7, 8, 9, 10, 11}
Processor1 {A12}
Processor2 {B12}
Configuration 7 12x 16 GB RDIMMs, 4x
NVDIMM-Ns
Same for all 12x RDIMM
configurations. See
Configuration 1.
Processor1 {A7, A8}
Processor2 {B7, B8}
Configuration 8 22x 32 GB RDIMMs, 4x
NVDIMM-Ns
Same for all 12x RDIMM
configurations. See
Configuration 1.
Processor1 {A7, A8}
Processor2 {B7, B8}
Configuration 9 20x 32 GB RDIMMs, 4x
NVDIMM-Ns
Processor1 {A1, 2, 3, 4, 5, 6, 7,
8, 9, 10}
Processor2 {B1, 2, 3, 4, 5, 6,
7, 8, 9, 10}
Processor1 {A11, 12}
Processor2 {B11, 12}
Configuration 10 12x 16 GB RDIMMs, 6x
NVDIMM-Ns
Same for all 12x RDIMM
configurations. See
Configuration 1.
Processor1 {A7, 8, 9}
Processor2 {B7, 8, 9}
Configuration 11 12x 32 GB RDIMMs, 6x
NVDIMM-Ns
Same for all 12x RDIMM
configurations. See
Configuration 1.
Processor1 {A7, 8, 9}
Processor2 {B7, 8, 9}
Installing and removing system components 47
