Dell Force10 Z9000 Configuration Guide

556 | Link Layer Discovery Protocol (LLDP)
www.dell.com | support.dell.com
Figure 25-15. Configuring LLDPDU Time to Live
Debugging LLDP
The command debug lldp enables you to view the TLVs that your system is sending and receiving.
• Use the
debug lldp brief command to view a readable version of the TLVs.
• Use the
debug lldp detail command to view a readable version of the TLVs plus a hexadecimal version
of the entire LLDPDU.
Figure 25-16. debug lldp detail—LLDPDU Packet Dissection
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
no disable
R1(conf-lldp)#multiplier ?
<2-10> Multiplier (default=4)
R1(conf-lldp)#multiplier 5
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
multiplier 5
no disable
R1(conf-lldp)#no multiplier
R1(conf-lldp)#show config
!
protocol lldp
advertise dot1-tlv port-protocol-vlan-id port-vlan-id
advertise dot3-tlv max-frame-size
advertise management-tlv system-capabilities system-description
no disable
R1(conf-lldp)#

Dell Force10 Z9000 Specifications

General

Switching Capacity	2.56 Tbps
Power Supply	Dual, hot-swappable
MTBF	200, 000 hours
Ports	32 x 40GbE QSFP+
Cooling	Front-to-back airflow
Form Factor	Fixed
Jumbo Frame Support	Up to 9216 bytes
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	10% to 90% (non-condensing)
MAC Address Table Size	128K
Dimensions (HxWxD)	3.45 in x 17.32 in x 20.0 in
