Quality of Service (QoS) | 733
Figure 35-12. Marking DSCP Values for Egress Packets
Set a dot1p value for egress packets
Set a dot1p value for egress packets using the command set mac-dot1p from QOS-POLICY-IN mode.
Create an output QoS policy
To create an output QoS policy:
1. Create an output QoS policy using the command
qos-policy-output from CONFIGURATION mode.
2. Once you configure an output QoS policy, do one or more of the following
• Configure policy-based rate limiting
• Configure policy-based rate shaping
• Allocate bandwidth to queue
• Specify WRED drop precedence
Configure policy-based rate limiting
Configure policy-based rate limiting is supported only on platform e
Policy-based rate limiting is configured the same way as port-based rate limiting except that the command
from QOS-POLICY-OUT mode is
rate-limit rather than rate limit as it is in INTERFACE mode.
Configure policy-based rate shaping
Rate shape egress traffic using the command rate-shape from QOS-POLICY-OUT mode.
Allocate bandwidth to queue
The E-Series schedules unicast, multicast, and replication traffic for egress based on the Weighted Fair
Queuing algorithm. The C-Series and S-Series schedule packets for egress based on Deficit Round Robin
(DRR). These strategies both offer a guaranteed data rate.
To allocate an amount bandwidth to a queue using the command
bandwidth-percentage on the E-Series.
FTOS#config
FTOS(conf)#qos-policy-input my-input-qos-policy
FTOS(conf-qos-policy-in)#set ip-dscp 34
% Info: To set the specified DSCP value 34 (100-010 b) the QoS policy must be mapped to queue
4 (100 b).
FTOS(conf-qos-policy-in)#show config
!
qos-policy-input my-input-qos-policy
set ip-dscp 34
FTOS(conf-qos-policy-in)#end
FTOS#
