Routing Information Protocol (RIP) | 747
36
Routing Information Protocol (RIP)
Routing Information Protocol (RIP) is supported only on platforms: e c s z
RIP is supported on the S-Series following the release of FTOS version 7.8.1.0, and on the C-Series with
FTOS versions 7.6.1.0 and after.
Routing Information Protocol (RIP) is based on a distance-vector algorithm, it tracks distances or hop
counts to nearby routers when establishing network connections.
• Protocol Overview on page 747
• Implementation Information on page 748
• Configuration Information on page 748
• RIP Configuration Example on page 756
RIP protocol standards are listed in the Appendix 50, Standards Compliance chapter.
Protocol Overview
RIP is the oldest interior gateway protocol. There are two versions of RIP: RIP version 1 (RIPv1) and RIP
version 2 (RIPv2). These versions are documented in RFCs 1058 and 2453.
RIPv1
RIPv1 learns where nodes in a network are located by automatically constructing a routing data table. The
routing table is established after RIP sends out one or more broadcast signals to all adjacent nodes in a
network. Hop counts of these signals are tracked and entered into the routing table, which defines where
nodes in the network are located.
The information that is used to update the routing table is sent as either a request or response message. In
RIPv1, automatic updates to the routing table are performed as either one-time requests or periodic
responses (every 30 seconds). RIP transports its responses or requests by means of UDP over port 520.
