Ports and Connectors
USB two 4-pin USB 2.0-compliant connectors and
one eSATA/USB 2.0-compliant connector
Memory card reader one 3-in-1 memory card reader
Contactless Smart Card
Supported Smart Cards/Technologies ISO14443A — 106 kbps, 212 kbps, 424 kbps,
and 848 kbps ISO14443B — 106 kbps, 212
kbps, 424 kbps, and 848 kbps ISO15693 HID
iClass FIPS201 NXP Desfire
Display
Type white Light Emitting Diode (WLED) display
Size 12.5 inch high definition (HD)
Dimensions:
Height 300.40 mm (7.58 inches)
Width 324.00 mm (12.76 inches)
Diagonal 355.60 mm (14.00 inches)
Active area (X/Y) 309.40 mm x 173.95 mm
Maximum resolution 1366 x 768 pixels at 262K colors
Maximum Brightness 200 nits
Operating angle 0° (closed) to 135°
Refresh rate 60 Hz
Minimum Viewing angles:
Horizontal +/- 40°
Vertical +10°/-30°
Pixel pitch 0.2265 mm
Keyboard
Number of keys: United States: 86 keys, United Kingdom: 87
keys, Brazil: 87 keys, and Japan: 90 keys
91
