88 Display
5 Replace the four screws that secure the display panel to the display back
cover.
6 Replace the display bezel (see "Replacing the Display Bezel" on page 85).
7 Replace the display assembly (see "Replacing the Display Assembly" on
page 82).
Display Hinges
Removing the Display Hinges
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the display assembly (see "Removing the Display Assembly" on
page 81).
3 Remove the display bezel (see "Removing the Display Bezel" on page 83).
4 Remove the display panel (see "Removing the Display Panel" on page 86).
5 Remove the eight screws (four on each side) that secure the display hinges
to the display back cover.
6 Remove the display hinges off the display back cover.
