Table 12. Storage controller cards (continued)
Supported storage controller cards
● PERC H965i
● PERC H755
● PERC H355
Internal Boot
● Boot Optimized Storage Subsystem (BOSS-N1): HWRAID 2 x M.2 SSDs or uSD card
Software RAID
● S160
SAS Hot Bus Adapters (HBA)
● HBA355i
Drives
The PowerEdge C6620 system supports:
● 16 x 2.5-inch SAS/SATA/NVMe (HDD/SSD) drives
● 8 x E3.s NVMe SSD drives
NOTE: For more information about how to hot swap NVMe PCIe SSD U.2 device, see the Dell Express Flash NVMe PCIe
SSD User's Guide at https://www.dell.com/support >Browse all Products > Data Center Infrastructure > Storage
Adapters & Controllers > Dell PowerEdge Express Flash NVMe PCIe SSD > Documentation > Manuals and
Documents.
Ports and connectors specifications
USB ports specifications
The PowerEdge C6620 system supports one USB 3.0 on the rear of each sled.
Display port specifications
The PowerEdge C6620 system supports one Mini-DisplayPort on the rear of each sled.
NIC port specifications
The PowerEdge C6620 system supports up to two 10/100/1000 Mbps Network Interface Controller (NIC) ports embedded on
the LAN on Motherboard (LOM) and integrated on the optional Open Compute Project (OCP) cards.
Table 13. NIC port specification for the system
Feature Specifications
LOM card 1 GbE x 1
OCP card (OCP 3.0) 1 GbE x 4, 10 GbE x 2, 25 GbE x 2, 25 GbE x 4
iDRAC9 port specifications
The PowerEdge C6620 system supports one iDRAC Direct port (Micro-AB USB 2.0-compliant port) on the rear of the system.
Technical specifications
23
